F7 E1 Error on Maytag Laundry — How to Figure Out and Solve?

Technically Reviewed by Oleg Chudnovski on Oct 28, 2025 | Written by Spark Service PRO Editorial Contributors

Maytag washing machines are designed with advanced features to enhance performance and efficiency. However, like any appliance, they can experience errors such as F7 E1, which indicates a malfunction. This guide outlines when this error typically appears, the components involved, and the steps to resolve it.

Maytag offers a range of top-load and front-load washers known for their durability, high-capacity drums, and smart technology integration. While these machines are built for reliability, occasional issues can arise, requiring proper troubleshooting and maintenance.

What Causes the F7 E1 Error and When Does It Happen

This error code on Maytag washing machines occurs when the washer's motor circuit experiences a prolonged period of high current draw.

This can happen during the wash or spin cycle when the motor encounters resistance or overload, causing the control board to detect an abnormal power consumption.

Book Online and Save $30 fixappliances.ca 1-888-242-0777 Use Coupon →

What Parts of a Maytag Washer Can Cause This Error?

There are several components that may potentially cause this kind of issue:

1. Drive Motor: the drive motor powers the drum's rotation during wash and spin cycles. Overloading or issues with the motor can trigger the F7 E1 error.
2. Motor Control Unit (MCU): the MCU regulates the power supplied to the drive motor. Malfunctions in the MCU can result in abnormal current draw, leading to the error code.
3. Wiring and Connections: damaged or loose wiring connecting the drive motor and MCU to the washing machine's control board can lead to communication issues and trigger the F7 E1 error.

Step-by-Step Guide to Fixing Error F7 E1

Resolving the F7 E1 error code involves a systematic approach to identify and address the next problems:

Step 1: Stop the Cycle

• If the F7 E1 error appears, stop the washing machine and allow it to pause the cycle. The machine will attempt to reset and continue after a brief pause.

Step 2: Inspect the Load

• Ensure that the laundry load is properly balanced and does not cause excessive resistance or overload on the motor.
• Remove any items that may be tangling or impeding the drum's rotation.

Step 3: Run Diagnostic Tests

• Maytag washing machines often have diagnostic modes that can help pinpoint the source of the problem. Refer to the user manual for instructions on running diagnostic tests.

Step 4: Check Wiring and Connections

• Turn off the washing machine and unplug it.
• Inspect the wiring and connections between the drive motor, MCU, and control board.
• Repair or replace any damaged wires or connectors.

Step 5: Restart the Wash Cycle

• Once the issues have been addressed, restart the washing machine and monitor its performance.
• If the F7 E1 error persists, consider running the machine with a smaller or lighter load to prevent overloading.

Step 6: Professional Help

• If you are still not sure what to do or decide to keep your time and efforts, you may contact our certified appliance technicians.

Summary of F7 E1 Maytag Washer Error

Resolving the F7 E1 error code in Maytag washing machines involves addressing motor current draw and load balance issues. This guide will help you to detect the cause of the error problem and solve it quickly.
